Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | KH-51 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Attachment Mounting Style | Panel Mount | |
| Device Type Classification | Illuminated | |
| Electrical Pathway | DPST-NO/NC | |
| Switch Operation Mode | On-Mom, Off-Mom | |
| Ampere Capacity Rating | 3A (AC), 270mA (DC) | |
| AC Voltage Max | 250 V | |
| DC Voltage Max | 250 V | |
| Activator Mechanism Type | Round, Button | |
| Activator Label Indicator | - | |
| Activator Cap Shade | Amber | |
| LED Illumination Shades | LED, Amber | |
| Standard Illumination Volts | 110 VDC | |
| Lead Termination Type | Screw Terminal | |
| Dust Water Resistance Rating | IP40 | |
| Key Product Highlights | - | |
| Mount Cutout Specs | Circular - 30.10mm Dia | |
| Ambient Temp Range | - |
Description
Incorporates a Round, Button actuator type to fulfill the desired function. Configured for circuit type described as DPST-NO/NC. Made with an actuator or cap color labeled as Amber for visual differentiation. Sets the ampere rating to 3A (AC), 270mA (DC). Includes LED, Amber colored LEDs for effective signaling. Works at a standard voltage of 110 VDC for illumination. Rated with IP IP40 to safeguard against dust and moisture penetration. Mounting configuration Panel Mount for structural stability. Type of housing Bulk for safeguarding or transporting components. Specifications of the cutout Circular - 30.10mm Dia for accurate mounting. Product status Active concerning availability and lifecycle. Classification series for the product or component KH-51. Modification in operation mode On-Mom, Off-Mom for electrical optimization. Type of termination Screw Terminal for connector or device. Type classification Illuminated for specifications. The highest AC voltage specification 250 V for the device. The highest DC voltage specification 250 V for components.
