Stock:
Distributor: 114
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 1,305.63000 | ₹ 1,305.63 |
| 11 | ₹ 1,205.06000 | ₹ 13,255.66 |
| 28 | ₹ 1,151.66000 | ₹ 32,246.48 |
| 57 | ₹ 1,118.73000 | ₹ 63,767.61 |
| 114 | ₹ 1,087.58000 | ₹ 1,23,984.12 |
| 227 | ₹ 1,043.97000 | ₹ 2,36,981.19 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | A3A | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Attachment Mounting Style | Panel Mount, Rear | |
| Device Type Classification | Standard | |
| Electrical Pathway | SPST-NO | |
| Switch Operation Mode | Off-On | |
| Ampere Capacity Rating | 6A (AC), 4A (DC) | |
| AC Voltage Max | 125 V | |
| DC Voltage Max | 30 V | |
| Activator Mechanism Type | Square, Button | |
| Activator Label Indicator | No Marking | |
| Activator Cap Shade | Black | |
| LED Illumination Shades | - | |
| Standard Illumination Volts | - | |
| Lead Termination Type | Solder Lug | |
| Dust Water Resistance Rating | IP00 | |
| Key Product Highlights | - | |
| Mount Cutout Specs | Square - 11.50mm x 11.50mm | |
| Ambient Temp Range | -10°C ~ 55°C |
Description
Features labels marked as No Marking for easy identification. Incorporates a Square, Button actuator type to fulfill the desired function. Configured for circuit type described as SPST-NO. Made with an actuator or cap color labeled as Black for visual differentiation. Sets the ampere rating to 6A (AC), 4A (DC). Rated with IP IP00 to safeguard against dust and moisture penetration. Mounting configuration Panel Mount, Rear for structural stability. Temperature range -10°C ~ 55°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Specifications of the cutout Square - 11.50mm x 11.50mm for accurate mounting. Product status Active concerning availability and lifecycle. Classification series for the product or component A3A. Modification in operation mode Off-On for electrical optimization. Type of termination Solder Lug for connector or device. Type classification Standard for specifications. The highest AC voltage specification 125 V for the device. The highest DC voltage specification 30 V for components.
