Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 100 | ₹ 1,527.57000 | ₹ 1,52,757.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | Tariff may apply if shipping to the United States | |
| Product Series Line | 58312 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Attachment Mounting Style | Panel Mount, Snap-In | |
| Electrical Pathway | SPDT | |
| Switch Operation Mode | On-Off-On | |
| Ampere Capacity Rating | 25A (DC) | |
| AC Voltage Max | - | |
| DC Voltage Max | 12 V | |
| Activator Mechanism Type | Concave (Curved) - Illuminated | |
| Activator Cap Shade | Black | |
| Activator Label Indicator | No Marking | |
| LED Illumination Shades | LED, Amber/Green | |
| Standard Illumination Volts | 12 VDC | |
| Lead Termination Type | Quick Connect - 0.250" (6.3mm) | |
| Dust Water Resistance Rating | IP66 - Dust Tight, Water Resistant | |
| Key Product Highlights | - | |
| Mount Cutout Specs | Rectangular - 36.83mm x 21.08mm | |
| Ambient Temp Range | - | |
| Certification Body | - |
Description
Features labels marked as No Marking for easy identification. Incorporates a Concave (Curved) - Illuminated actuator type to fulfill the desired function. Assesses resistance at forward current Tariff may apply if shipping to the United States for LED or diode testing. Configured for circuit type described as SPDT. Made with an actuator or cap color labeled as Black for visual differentiation. Sets the ampere rating to 25A (DC). Includes LED, Amber/Green colored LEDs for effective signaling. Works at a standard voltage of 12 VDC for illumination. Rated with IP IP66 - Dust Tight, Water Resistant to safeguard against dust and moisture penetration. Mounting configuration Panel Mount, Snap-In for structural stability. Type of housing Bulk for safeguarding or transporting components. Specifications of the cutout Rectangular - 36.83mm x 21.08mm for accurate mounting. Product status Active concerning availability and lifecycle. Classification series for the product or component 58312. Modification in operation mode On-Off-On for electrical optimization. The classification for import duties Tariff may apply if shipping to the United States related to import and export transactions. Type of termination Quick Connect - 0.250" (6.3mm) for connector or device. Maximum Vce(on) at Vge Tariff may apply if shipping to the United States for transistor specifications. The highest DC voltage specification 12 V for components.
