Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | NS22 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Device Type Classification | Standard | |
| Electrical Pathway | DPST-NO/NC | |
| Switch Position Options | 2 | |
| Switch Operation Mode | Off-On | |
| Ampere Capacity Rating | 3A (AC), 270mA (DC) | |
| AC Voltage Max | 250 V | |
| DC Voltage Max | 250 V | |
| Backlighting Feature | Non-Illuminated | |
| LED Illumination Shades | - | |
| Standard Illumination Volts | - | |
| Attachment Mounting Style | Panel Mount | |
| Lead Termination Type | Screw Terminal | |
| Mount Cutout Specs | Circular - 22.30mm Dia | |
| Dust Water Resistance Rating | IP65 - Dust Tight, Water Resistant | |
| Key Product Highlights | - | |
| Ambient Temp Range | -25°C ~ 70°C |
Description
Configured for circuit type described as DPST-NO/NC. Sets the ampere rating to 3A (AC), 270mA (DC). Provides Non-Illuminated brightness for improved visibility. Rated with IP IP65 - Dust Tight, Water Resistant to safeguard against dust and moisture penetration. Mounting configuration Panel Mount for structural stability. Overall number of positions 2 for switches or mechanical components. Temperature range -25°C ~ 70°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Specifications of the cutout Circular - 22.30mm Dia for accurate mounting. Product status Active concerning availability and lifecycle. Classification series for the product or component NS22. Modification in operation mode Off-On for electrical optimization. Type of termination Screw Terminal for connector or device. Type classification Standard for specifications. The highest AC voltage specification 250 V for the device. The highest DC voltage specification 250 V for components.
