Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | A165W | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Device Type Classification | Standard | |
| Electrical Pathway | DPDT | |
| Switch Position Options | 3 | |
| Switch Operation Mode | On-On-On | |
| Ampere Capacity Rating | 5A (AC), 3A (DC) | |
| AC Voltage Max | 125 V | |
| DC Voltage Max | 30 V | |
| Backlighting Feature | Illuminated | |
| LED Illumination Shades | LED, Green | |
| Standard Illumination Volts | 24 VDC | |
| Attachment Mounting Style | Panel Mount | |
| Lead Termination Type | Solder, Quick Connect - 0.110" (2.8mm) | |
| Mount Cutout Specs | Circular - 16.00mm Dia | |
| Dust Water Resistance Rating | IP65 - Dust Tight, Oil and Water Resistant | |
| Key Product Highlights | Bezel - Square | |
| Ambient Temp Range | -10°C ~ 55°C |
Description
Configured for circuit type described as DPDT. Sets the ampere rating to 5A (AC), 3A (DC). Equipped with features categorized as Bezel - Square. Provides Illuminated brightness for improved visibility. Includes LED, Green colored LEDs for effective signaling. Works at a standard voltage of 24 VDC for illumination. Rated with IP IP65 - Dust Tight, Oil and Water Resistant to safeguard against dust and moisture penetration. Mounting configuration Panel Mount for structural stability. Overall number of positions 3 for switches or mechanical components. Temperature range -10°C ~ 55°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Specifications of the cutout Circular - 16.00mm Dia for accurate mounting. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component A165W. Modification in operation mode On-On-On for electrical optimization. Type of termination Solder, Quick Connect - 0.110" (2.8mm) for connector or device. Type classification Standard for specifications. The highest AC voltage specification 125 V for the device. The highest DC voltage specification 30 V for components.
