Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | B3D | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Electrical Pathway | SPST-NO | |
| Switch Operation Mode | Off-Mom | |
| Pin Voltage Tolerance | 0.01A @ 12VDC | |
| Activator Mechanism Type | Snap Dome | |
| Attachment Mounting Style | Surface Mount, Adhesive | |
| Vertical Activator PCB Height | - | |
| Right-Angle Activator Length | - | |
| Activator Alignment Direction | Top Actuated | |
| Lead Termination Type | Circular Contact | |
| Dimensional Outline Drawing | - | |
| Backlighting Feature | Non-Illuminated | |
| LED Illumination Shades | - | |
| Standard Illumination Volts | - | |
| Activation Pressure Required | 167gf | |
| Dust Water Resistance Rating | Dust Proof | |
| Key Product Highlights | - | |
| Ambient Temp Range | -40°C ~ 80°C |
Description
Aligned with Top Actuated actuator orientation for precise placement. Incorporates a Snap Dome actuator type to fulfill the desired function. Configured for circuit type described as SPST-NO. Offers a contact rating at the voltage level of 0.01A @ 12VDC. Provides Non-Illuminated brightness for improved visibility. Rated with IP Dust Proof to safeguard against dust and moisture penetration. Mounting configuration Surface Mount, Adhesive for structural stability. Pressure applied 167gf for ergonomic or mechanical operations. Temperature range -40°C ~ 80°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component B3D. Modification in operation mode Off-Mom for electrical optimization. Type of termination Circular Contact for connector or device.
