Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 25 | ₹ 12,750.13000 | ₹ 3,18,753.25 |
| 10 | ₹ 13,401.05000 | ₹ 1,34,010.50 |
| 1 | ₹ 15,545.24000 | ₹ 15,545.24 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | AML25 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Attachment Mounting Style | Panel Mount, Snap-In | |
| Electrical Pathway | DPDT | |
| Switch Operation Mode | On-On | |
| Ampere Capacity Rating | 3A (AC), 2A (DC) | |
| AC Voltage Max | 125 V | |
| DC Voltage Max | 24 V | |
| Activator Mechanism Type | Paddle | |
| Activator Arm Length | - | |
| Backlighting Feature | Illuminated | |
| LED Illumination Shades | LED, Green/Red | |
| Standard Illumination Volts | 24 VDC | |
| Lead Termination Type | Solder, Quick Connect - 0.110" (2.8mm) | |
| Mount Cutout Specs | Rectangular - 28.98mm x 19.05mm | |
| Insulator Thread Pattern | - | |
| Dust Water Resistance Rating | - | |
| Key Product Highlights | - | |
| Ambient Temp Range | - |
Description
Incorporates a Paddle actuator type to fulfill the desired function. Configured for circuit type described as DPDT. Sets the ampere rating to 3A (AC), 2A (DC). Provides Illuminated brightness for improved visibility. Includes LED, Green/Red colored LEDs for effective signaling. Works at a standard voltage of 24 VDC for illumination. Mounting configuration Panel Mount, Snap-In for structural stability. Type of housing Bulk for safeguarding or transporting components. Specifications of the cutout Rectangular - 28.98mm x 19.05mm for accurate mounting. Product status Active concerning availability and lifecycle. Classification series for the product or component AML25. Modification in operation mode On-On for electrical optimization. Type of termination Solder, Quick Connect - 0.110" (2.8mm) for connector or device. The highest AC voltage specification 125 V for the device. The highest DC voltage specification 24 V for components.
