Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 15,294.55000 | ₹ 15,294.55 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | i.MX 93 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Central CPU Unit | ARM® Cortex®-A55 | |
| Operational Speed Rating | 1.7GHz | |
| Processor Core Number | 2 | |
| Wattage Power Level | 12.5W | |
| Thermal Management Method | Heat Sink | |
| Package Size Specs | 1.771" x 1.771" (45.00mm x 45.00mm) | |
| Device Size Standard | OSM | |
| Expansion Slot Bus Type | I2C, SPI, UART | |
| Installed RAM Volume | 2GB | |
| Memory Bus Interface | eMMC | |
| Display Video Ports | LVDS, MIPI CSI, MIPI DSI | |
| Network Ethernet Standard | GbE (1) | |
| USB Interface Version | USB 2.0 (3), USB 2.0 OTG (1) | |
| Serial Port Standards | 0 | |
| Digital Input/Output Pins | 15 | |
| Analog Signal In to Out | - | |
| System Monitor Timer | - | |
| Included Components | - | |
| Ambient Temp Range | -40°C ~ 85°C |
Description
Utilizes a cooling method identified as Heat Sink. Includes the core processor identified as ARM® Cortex®-A55 for swift processing. Provides a total of 15 digital input/output pins. Conforms to the Ethernet standard specified at GbE (1). Has an expansion slot or bus type specified at I2C, SPI, UART. Shows a form factor labeled as OSM. The total number of cores is 2 for processors or cables. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Power measured in watts 12.5W for optimal operation. Product status Active concerning availability and lifecycle. The total capacity of the installed RAM 2GB for optimal computing performance. The standards RS-232/422/485 0 for serial data communication. Classification series for the product or component i.MX 93. Details on package size 1.771" x 1.771" (45.00mm x 45.00mm) for electrical or mechanical components. Measurement dimensions 1.771" x 1.771" (45.00mm x 45.00mm) for component specifications. Operational speed 1.7GHz for mechanical or data tasks. Connection interface eMMC for storage integration. Version of USB USB 2.0 (3), USB 2.0 OTG (1) for connectivity. Video interfaces LVDS, MIPI CSI, MIPI DSI for display or graphics output.
