Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Box | |
| Availability Status | Active | |
| Device Type Classification | DC Motor | |
| Primary Function Mode | Gearmotor | |
| Electric Motor Design | Brushed | |
| Rated Operating Voltage | 3 ~ 6VDC | |
| Revolutions Per Minute | 430 RPM | |
| Nominal Torque Value | 0.7 / 4.9 | |
| Nominal Power Rating | - | |
| Position Encoder Category | - | |
| Package Size Specs | Rectangular - 0.472" x 0.394" (12.00mm x 10.00mm) | |
| Shaft Rod Width | 0.118" (3.00mm) | |
| Shaft Bearing Total Length | 0.394" (10.00mm) | |
| Screw Hole Pitch | 0.354" (9.00mm) | |
| Lead Termination Type | Quick Connect | |
| Key Product Highlights | - | |
| Speed Reduction Gear Ratio | - | |
| Peak Instant Torque | - | |
| Ambient Temp Range | -10°C ~ 60°C |
Description
Defines the shaft diameter as 0.118" (3.00mm). Engineered with Gearmotor features for versatile component usage. Total length of the shaft and bearing 0.394" (10.00mm) for smooth assembly. Type of motor Brushed for mechanical functionality. Spacing between mounting holes 0.354" (9.00mm) for correct alignment. Temperature range -10°C ~ 60°C for environmental conditions impacting thermal efficiency. Type of housing Box for safeguarding or transporting components. Product status Active concerning availability and lifecycle. The RPM value 430 RPM for motors or mechanical devices. Details on package size Rectangular - 0.472" x 0.394" (12.00mm x 10.00mm) for electrical or mechanical components. Measurement dimensions Rectangular - 0.472" x 0.394" (12.00mm x 10.00mm) for component specifications. Type of termination Quick Connect for connector or device. Designated torque 0.7 / 4.9 in oz-in/mNm for classification. Type classification DC Motor for specifications. The operating voltage rating of the device 3 ~ 6VDC.
