Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | Lexium SD3 | |
| IC Encapsulation Type | Box | |
| Availability Status | Active | |
| Device Type Classification | Hybrid | |
| Electromagnetic Coil Design | Bipolar | |
| Rated Operating Voltage | 34 ~ 48VDC | |
| Ampere Capacity Rating | 5.8 A | |
| Revolution Step Count | 200.0 | |
| Stepper Motor Step Degrees | 1.8° | |
| Precision Level | ±6% | |
| Holding Torque Rating | 144.4 / 1020 | |
| Package Size Specs | Square - 2.252" x 2.252" (57.20mm x 57.20mm) | |
| Motor Frame Standard | - | |
| Shaft Rod Width | 0.250" (6.35mm) | |
| Shaft Bearing Total Length | 0.827" (21.00mm) | |
| Screw Hole Pitch | 1.496" (38.00mm) | |
| Lead Termination Type | Connector | |
| Ambient Temp Range | -25°C ~ 40°C | |
| Inductor Resistance Value | 0.5 Ohms | |
| Key Product Highlights | - |
Description
Delivers measurement precision rated at ±6% for reliable results. Features a coil resistance measured at 0.5 Ohms to maintain consistent electromagnetic performance. Designed with a coil type classified as Bipolar for optimal electrical efficiency. Sets the ampere rating to 5.8 A. Defines the shaft diameter as 0.250" (6.35mm). Total length of the shaft and bearing 0.827" (21.00mm) for smooth assembly. Spacing between mounting holes 1.496" (38.00mm) for correct alignment. Temperature range -25°C ~ 40°C for environmental conditions impacting thermal efficiency. Type of housing Box for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Classification series for the product or component Lexium SD3. Details on package size Square - 2.252" x 2.252" (57.20mm x 57.20mm) for electrical or mechanical components. Measurement dimensions Square - 2.252" x 2.252" (57.20mm x 57.20mm) for component specifications. Step angle 1.8° related to stepper motors. Total steps per revolution 200.0 for rotating mechanisms. Type of termination Connector for connector or device. Torque retention 144.4 / 1020 in oz-in/mNm for reliability. Type classification Hybrid for specifications. The operating voltage rating of the device 34 ~ 48VDC.
