Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 1,674.02000 | ₹ 1,674.02 |
Stock:
Distributor: 126
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 2,169.02000 | ₹ 2,169.02 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | Tariff may apply if shipping to the United States | |
| Product Series Line | LI150-20BxxPR2 (150) | |
| IC Encapsulation Type | Box | |
| Availability Status | Not For New Designs | |
| Entry Signal Category | AC or DC | |
| Signal Output Quantity | 1 | |
| AC Input Voltage Rating | 85 ~ 264 VAC | |
| Min DC Input Volts | 120V | |
| Max DC Input Volts | 370V | |
| First Rail Output Volts | 48V | |
| Second Rail Output Volts | - | |
| Third Rail Output Volts | - | |
| Fourth Rail Output Volts | - | |
| Fifth Rail Output Volts | - | |
| Sixth Rail Output Volts | - | |
| Peak Output Current | 3.2A | |
| Wattage Power Level | 154W | |
| Isolation Barrier Voltage | 4 kV | |
| Intended Uses | Household Appliances, ITE (Commercial) | |
| Performance Efficiency Rating | 91% | |
| Ambient Temp Range | -30°C ~ 70°C (With Derating) | |
| Key Product Highlights | Adjustable Output, Universal Input | |
| Package Size Specs | 2.28" L x 4.13" W x 3.54" H (58.0mm x 105.0mm x 90.0mm) | |
| Certification Body | CE, EN | |
| Compliance Standard ID | 60335-1; 62368-1 |
Description
Supports an AC input voltage rated at 85 ~ 264 VAC for extensive operational compatibility. Perfectly designed for situations involving Household Appliances, ITE (Commercial). Complies with the criteria of entities acknowledged as CE, EN. Assesses resistance at forward current Tariff may apply if shipping to the United States for LED or diode testing. Supplies peak output current defined as 3.2A. Allows for a maximum DC input voltage of 370V. Requires a minimum DC input voltage of 120V. Offers an efficiency rating calculated at 91%. Equipped with features categorized as Adjustable Output, Universal Input. Configured with AC or DC input type for diverse applications. The input voltage established at 85 ~ 264 VAC for reliable performance. Overall outputs 1 for device connections. Temperature range -30°C ~ 70°C (With Derating) for environmental conditions impacting thermal efficiency. Voltage 48V for optimal output electric potential. Type of housing Box for safeguarding or transporting components. Power measured in watts 154W for optimal operation. Product status Not For New Designs concerning availability and lifecycle. Classification series for the product or component LI150-20BxxPR2 (150). Details on package size 2.28" L x 4.13" W x 3.54" H (58.0mm x 105.0mm x 90.0mm) for electrical or mechanical components. Measurement dimensions 2.28" L x 4.13" W x 3.54" H (58.0mm x 105.0mm x 90.0mm) for component specifications. Standard compliance code 60335-1; 62368-1 for regulations. The classification for import duties Tariff may apply if shipping to the United States related to import and export transactions. Maximum Vce(on) at Vge Tariff may apply if shipping to the United States for transistor specifications. Isolation voltage 4 kV for electrical safety. Output 1 voltage 48V across different outputs.
